PERFORMANCE
Processor
Intel® Core™ Ultra 5 225 (Series 2), 10 Cores / 10 Threads, up to 4.9GHz Turbo, 20MB Intel® Smart Cache
Processor Manufacturer
Intel®
Processor Generation
Intel® Core™ Ultra (Series 2)
Performance Cores
6
Efficient Cores
4
Performance-core Max Turbo Frequency
Up to 4.9 GHz
Efficient-core Max Turbo Frequency
Up to 4.4 GHz
Performance-core Base Frequency
3.3 GHz
Efficient-core Base Frequency
2.7 GHz
Processor Cache
20MB Intel® Smart Cache
Number of Processors Installed
1
Processor Base Power
65W
Maximum Turbo Power
121W
Neural Processor (NPU)
Intel® AI Boost
NPU Features
Sparsity Support
Windows Studio Effects Support
AI Framework Support
DirectML
OpenVINO
Windows ML
ONNX Runtime
WebNN
AI Performance
Total Processor Performance: Up to 23 TOPS
NPU Performance: Up to 13 TOPS
GPU Performance: Up to 4 TOPS
Graphics
Integrated Intel® Graphics
Chipset
Intel® Q670
Memory
16GB DDR5-4800 (1 x 16GB)
Memory Slots
2 x DIMM
Max Memory
Up to 32GB DDR5
Memory Type
Unbuffered (Non-ECC)
Storage
512GB M.2 PCIe® 3.0 NVMe® SSD
Storage Slots
1 x M.2 SSD
Optical Drive
None
DESIGN
Chassis Type
Slim PC
Product Colour
Black
Dimensions (W x D x H)
95 x 293 x 303.5 mm
CONNECTIVITY
Wireless
Wi-Fi 6 (802.11ax)
Bluetooth®
Wireless Controller
MediaTek MT7920 (2x2)
Ethernet
Realtek RTL8111KD Gigabit Ethernet (10/100/1000)
Ports
4 x USB 2.0
3 x USB 3.2 Gen 1 Type-A
1 x USB 3.2 Gen 1 Type-C
1 x HDMI 2.1
1 x DisplayPort 1.4
1 x RJ-45 Ethernet
1 x Headphone / Microphone Combo Jack
Expansion Slots
3 x PCIe x1
1 x PCIe x16
1 x SATA III
AUDIO
Audio Chip
Realtek ALC3204
Audio System
High Definition Audio
SECURITY
Security Chip
Trusted Platform Module (TPM) 2.0
Physical Security
Kensington Lock Slot
SOFTWARE
Operating System
Windows 11 Pro (64-bit)
Trial Software
McAfee® Business Protection (1 Year)
Microsoft 365 30-Day Trial
POWER
Power Supply
180W
Input Voltage
90–264V AC
Input Frequency
47–63Hz
Efficiency
80 PLUS Bronze
ACCESSORIES
Keyboard
Dell Wired Keyboard KB216, UK (QWERTY), Black
Mouse
Dell Optical Mouse MS116, Black
Cables Included
AC Power Cable
CERTIFICATIONS & ENVIRONMENT
Operating Conditions
Operating Temperature: 10°C to 35°C
Storage Temperature: -40°C to 65°C
Operating Humidity: 20% to 80%
Storage Humidity: 5% to 95%
Operating Altitude: -15.2 to 3,048 m
Storage Altitude: -15.2 to 10,668 m
Operating Vibration: 0.26 G
Storage Vibration: 1.37 G
Operating Shock: 40 G
Storage Shock: 105 G
Carbon Footprint
Total: 143 kg CO2e
Manufacturing: 68.07 kg CO2e
Logistics: 9.15 kg CO2e
Energy Usage: 62.78 kg CO2e
End-of-life: 3 kg CO2e
PAIA Version: GaBi Version 1, 2025
