| Product Dimensions |
144x147x164 mm |
| Heatsink Dimensions |
140x110x160 mm |
| Net Weight |
1575 g |
| Heatpipe |
6 mm x 7 pcs |
| Fan Dimensions |
140x140x25 mm / 120x120x25 mm |
| Fan Speed (Performance Mode) |
500~1700 RPM + 10% |
| Fan Airflow (Performance Mode) |
79.1 CFM / 58.06 CFM |
| Fan Air Pressure (Performance Mode) |
2.44 mmAq / 2.1 mmAq |
| Overall Noise (Performance Mode) |
=29.3 dB(A) |
| Fan Speed (Quiet Mode) |
500~1350 RPM + 10% |
| Fan Airflow (Quiet Mode) |
63.76 CFM / 46.75 CFM |
| Fan Air Pressure (Quiet Mode) |
1.58 mmAq / 1.35 mmAq |
| Overall Noise (Quiet Mode) |
=22.6 dB(A) |
| Fan Connector |
4-pin PWM |
| Bearing Type |
Fluid Dynamic Bearing |
| Motor Type |
6-Pole Fan Motor |
| Fan Rated Voltage |
12 VDC |
| Fan Rated Current |
0.1 A / 0.07 A |
| Fan Power Consumption |
1.2 W / 0.84 W |
| Rated Voltage |
12 VDC |
| Power Consumption(Performance Mode) |
2.88 W |
| Power Consumption(Quiet Mode) |
1.56 W |
