GIGABYTE X870 GAMING X WIFI7 AM4 Motherboard (DDR5, Wi-Fi 7, Dual USB4, PCIe 5.0)
- 📦 Condition: Brand New, Factory Sealed
- 🚚 Shipping: Fast & Free Standard Shipping
Product Description
Take your system architecture to the absolute bleeding edge with the high-performance GIGABYTE X870 GAMING X WIFI7 motherboard. Specifically engineered for the AMD Socket AM5 ecosystem, this powerhouse fully supports AMD Ryzen 9000, 8000, and 7000 Series desktop processors. Featuring a heavy-duty Digital Twin 16+2+2 phases VRM solution alongside comprehensive full-metal Thermal Armor, it delivers rock-solid power delivery and exceptional system overclocking stability.
The GAMING X series completely reimagines the building and user experience with innovative, tool-less EZ-Latch and EZ-Plug designs for quick-release PCIe slots, screwless M.2 thermal guards, and effortless Wi-Fi antenna setup. Boasting future-proofed connectivity, it features ultra-fast dual 40Gbps USB4 Type-C ports with DisplayPort-Alt mode, next-generation Wi-Fi 7 wireless networking, and blazing-fast PCIe 5.0 lanes for elite storage and enthusiast graphics configurations.
Key Features
- Next-Gen AMD AM5 Support: Fully compatible with premium AMD Ryzen 9000, 8000, and 7000 Series processors out of the box.
- Elite DDR5 Performance: Supports 4 x DIMMs up to a massive 256GB capacity, pushing overclocked frequencies up to an extreme 8000(OC) MT/s with AMD EXPO profile support.
- Dual 40Gbps USB4 Type-C: Delivers astonishing data transfer rates alongside integrated multi-monitor ultra-HD DisplayPort outputs.
- Cutting-Edge Wi-Fi 7 & 2.5G LAN: Unlocks ultra-wide 160MHz channels on the 6GHz band with an ultra-high gain antenna for lag-free VR and seamless connectivity.
- Tool-Less EZ-Latch Assembly: Simplifies PC building with quick-release PCIe x16 slots, tool-free M.2 drive installations, and click-on heatsinks.
- Smart Fan 6 Cooling: Features comprehensive temperature layout matrices, dedicated liquid cooling water-flow monitoring, and automated Fan Stop quiet tuning.
Technical Specifications
| Specification Field | Details |
|---|---|
| CPU & Chipset Architecture | |
| Motherboard Model | GIGABYTE X870 GAMING X WIFI7 |
| Processor Socket | AMD Socket AM5 |
| CPU Compatibility | AMD Ryzen™ 9000 Series / 8000 Series / 7000 Series Processors |
| Chipset | AMD X870 Express Chipset |
| Power Delivery (VRM) | Digital Twin 16+2+2 Phases VRM Solution |
| Memory Specifications | |
| Memory Architecture | Dual-Channel, 4 x DDR5 DIMM Sockets |
| Maximum System Memory | Up to 256 GB (64 GB Single DIMM Capacity) |
| Supported Profiles | AMD EXtended Profiles for Overclocking (AMD EXPO™) & Intel XMP |
| Overclocked Speeds | DDR5 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) down to native 5200 / 4800 MT/s |
| Expansion Slots & Storage Interfaces | |
| Primary PCIe Slot | 1 x PCIe 5.0 x16 slot (Supports PCIe 5.0 x16 with Ryzen 9000/7000 series) |
| Chipset Expansion | 2 x PCIe 3.0 x16 slots (Running at x1 mode) |
| M.2 NVMe Slots | 3 x M.2 Connectors (1 x PCIe 5.0 x4 from CPU, 2 x PCIe 4.0 from Chipset) |
| SATA Ports & RAID | 4 x SATA 6Gb/s ports; Supports RAID 0, RAID 1, RAID 5, and RAID 10 (NVMe/SATA) |
| Connectivity & Onboard I/O | |
| Wireless Module | MediaTek/Realtek Wi-Fi 7 (802.11be, 160MHz, 2.4/5/6 GHz Bands) + Bluetooth 5.4 |
| Wired LAN | Realtek 2.5GbE LAN Chip (2.5 Gbps/1000 Mbps/100 Mbps) |
| Audio Controller | Realtek High Definition Audio CODEC (2/4/5.1/7.1-channel support) |
| Rear USB4 Ports | 2 x USB4 Type-C ports (Supports up to 40Gbps per port & DisplayPort outputs) |
| Onboard Video Outputs | 2 x USB4 Type-C (3840x2160@240 Hz), 1 x HDMI port (4096x2160@60 Hz) |
