Intel Core i9-14900F, 24 Cores, 32 Threads, 5.8GHz, LGA 1700, Box

Intel Core i9-14900F, 24 Cores, 32 Threads, 5.8GHz, LGA 1700, Box

DescriptionSpecs

• Intel Core i9 (14th Gen) — Raptor Lake, LGA 1700
• 24 Cores / 32 Threads — 8 Performance + 16 Efficient cores
• P-Core: 2.0 GHz base / 5.4 GHz boost — E-Core: 1.5 GHz base / 4.3 GHz boost
• Thermal Velocity Boost — 5.8 GHz (Turbo Boost Max 3.0: 5.6 GHz)
• 36 MB L3 Smart Cache + 32 MB L2 Cache
• TDP — 65 W base / 219 W max turbo
• Socket — LGA 1700, compatible with Z790, B760, H770 motherboards
• Memory — DDR4 & DDR5 dual-channel, up to 192 GB, 89.6 GB/s bandwidth
• PCIe 5.0 & 4.0 — 20 lanes maximum
• No integrated graphics — discrete GPU required
• Box packaging — cooler included

Overview

The Intel Core i9-14900F is Intel's flagship consumer desktop processor from the 14th Generation Raptor Lake lineup. With 24 cores (8 Performance + 16 Efficient) and 32 threads, it delivers exceptional multi-threaded throughput for gaming, content creation, streaming, and professional workloads. The Thermal Velocity Boost frequency reaches 5.8 GHz on the best cores. The F suffix denotes no integrated graphics — a discrete GPU is required. Ships in retail Box packaging with a stock cooler included.

Performance

24 Cores / 32 Threads — Hybrid Architecture
8 P-cores boost to 5.4 GHz for demanding single-threaded tasks. 16 E-cores handle background and parallel workloads at up to 4.3 GHz. Intel Thread Director intelligently assigns tasks to the right core type.

5.8 GHz Thermal Velocity Boost
Turbo Boost Max 3.0 prioritises the two fastest cores at up to 5.6 GHz. Thermal Velocity Boost pushes the best core to 5.8 GHz when thermal headroom allows. Intel Adaptive Boost Technology extends multi-core boost frequencies further.

36 MB L3 Smart Cache + 32 MB L2
Large combined cache reduces memory latency for gaming and data-intensive workloads.

PCIe 5.0 & 4.0 — 20 Lanes
Full PCIe 5.0 support for the latest GPUs and NVMe SSDs. Configurations: 1x16+1x4 or 2x8+1x4. DMI 4.0 with 8 lanes.

Memory Support

Supports DDR4-SDRAM and DDR5-SDRAM in dual-channel configuration, up to 192 GB. Maximum memory bandwidth: 89.6 GB/s.

Graphics

No integrated graphics (F-series). A discrete graphics card is required.

Key Technologies

Hyper-Threading — 2 threads per P-core. Turbo Boost 2.0 — automatic frequency scaling. Turbo Boost Max 3.0 — 5.6 GHz on best cores. Thermal Velocity Boost — 5.8 GHz. Adaptive Boost — extended multi-core boost. Thread Director — hardware OS task scheduling. Speed Shift — hardware P-state control. SpeedStep — dynamic voltage/frequency scaling. AES-NI — hardware encryption. VT-x / VT-d — virtualisation. GNA 3.0 — AI inference accelerator. DL Boost — deep learning via AVX 2.0. Boot Guard & OS Guard — platform security. CET — control-flow enforcement. Secure Key — hardware RNG. VMD — NVMe management. ISM — standard manageability. Execute Disable Bit, Idle States, Thermal Monitoring — security and power management.

What's Included

Intel Core i9-14900F processor (Box), Intel stock cooler, documentation.

Technical Specifications

Processor

Cache

Power

Memory

Graphics

Connectivity and I/O

Instruction Sets and Technologies
