PERFORMANCE
Processor
AMD Ryzen™ 7 170 (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
Graphics
Integrated AMD Radeon™ 680M Graphics
Chipset
AMD SoC Platform
Memory
16GB DDR5-4800 (1 x 16GB SODIMM)
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-4800
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 1TB M.2 2242 SSD
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2
Microphone
2x Array Microphones
Camera
HD 720p Camera with Privacy Shutter
Battery
47Wh
Power Adapter
65W Round Tip (3-pin)
DESIGN
Display
14" FHD (1920 x 1080) TN, 300 nits, Anti-glare, 45% NTSC, 60Hz
Touchscreen
None
Screen-to-Body Ratio
87%
Pen
Pen Not Supported
Keyboard
Non-backlit, English (UK)
Touchpad
Buttonless Mylar® Surface Multi-touch Touchpad, supports Precision TouchPad (PTP), 70 x 105 mm (2.76 x 4.13 inches)
Dimensions (W x D x H)
324.2 x 215.2 x 19.9 mm (12.76 x 8.47 x 0.78 inches)
Weight
Starting at 1.37 kg (3.02 lbs)
Case Color
Business Black
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment
Texture
SOFTWARE
Operating System
Windows® 11 Pro, English (US) / English (UK)
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6 (802.11ax 2x2) + Bluetooth® 5.2
WWAN
WWAN Not Supported
Ethernet
100/1000M (RJ-45)
Standard Ports
2 x USB-A (USB 5Gbps)
1 x USB-C® (USB 10Gbps) with USB Power Delivery 45-65W and DisplayPort™ 1.2
1 x HDMI® 1.4b
1 x Headphone / Microphone Combo Jack (3.5mm)
1 x Ethernet (RJ-45)
1 x Round Tip Power Connector
Docking
Various docking solutions supported via USB-C®
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™ (2.5 x 6 mm)
Fingerprint Reader
No Fingerprint Reader
Other Security
Camera Privacy Shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
ErP Lot 6/26
RoHS Compliant
Mil-Spec Test
MIL-STD-810H Military Test Passed
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
