MSI MAG Pano 100R PZ Midi Tower Gaming Case – Black
Overview
The MSI MAG Pano 100R PZ is a premium midi tower gaming case featuring a stunning 270-degree panoramic tempered glass design that showcases your build from every angle. With 4x pre-installed ARGB fans (3x 120mm reverse-blade side fans + 1x 120mm rear fan), support for up to 360mm radiators, and a spacious interior accommodating ATX, Micro-ATX, and Mini-ITX motherboards, it combines breathtaking aesthetics with serious cooling capability. Available in Black.
Key Technology Features
270° Panoramic Tempered Glass
Three-sided panoramic tempered glass panels with chamfered edges provide an unobstructed view of your entire build — front, side, and top — for maximum visual impact. 4mm tempered glass with chamfering technique minimises edge gaps.
4x Pre-Installed ARGB Fans
3x 120mm ARGB reverse-blade fans on the side and 1x 120mm ARGB fan at the rear, pre-installed. 1-to-4 ARGB fan control board included. Supports up to 3 additional fans on top and 3 on the bottom.
360mm Radiator Support
Supports 360mm AIO liquid coolers on the side, top, and bottom panels. Rear supports 120mm. Push-pull radiator configurations supported on the side.
UNI Front Panel Cable & Tool-Free Design
MSI's UNI front panel cable design simplifies installation. Front, side, and top panels are tool-free to remove. USB 3.2 Gen 2 Type-C (20Gbps) front port with MSI motherboard synergy bridging support.
Removable Dust Filters
Easily removable dust filters on the top, side, and bottom panels for simple maintenance and long-term cleanliness.
Spacious Interior
Supports GPUs up to 380mm, CPU coolers up to 166mm, and PSUs up to 200mm. 8 expansion slots. 2x 3.5" and 3x 2.5" storage bays.
What's Included
MSI MAG Pano 100R PZ Black case with 4x pre-installed ARGB fans (3x side reverse-blade + 1x rear), 1-to-4 ARGB control board, panoramic tempered glass panels, removable dust filters. PSU not included.
Technical Specifications
Main Specifications
| Form Factor | Midi Tower |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX |
| Material | Tempered Glass + Metal |
| Colour | Black |
| Side Panel | 270° Panoramic Tempered Glass (4mm chamfered) |
| Dimensions (W×D×H) | 290 × 518.7 × 482 mm |
| Expansion Slots | 8 |
Clearance
| Max CPU Cooler Height | 166 mm |
| Max GPU Length | 380 mm |
| Max PSU Length | 200 mm |
| PSU Form Factor | ATX |
| PSU Location | Bottom |
Fan Support
| Side | 3× 120mm ARGB reverse-blade installed (supports 120/140mm, max 3) |
| Rear | 1× 120mm ARGB installed (supports 120mm, max 1) |
| Top | None installed (supports 120/140mm, max 3) |
| Bottom | None installed (supports 120/140/160mm, max 3) |
| Pre-Installed Fans | 4× 120mm ARGB |
Radiator Support
| Side | 120 / 240 / 360mm |
| Top | 120 / 240 / 360mm |
| Bottom | 120 / 240 / 360mm |
| Rear | 120mm |
Storage
| 3.5" Drive Bays | 2 |
| 2.5" Drive Bays | 3 |
Front I/O
| USB 3.2 Gen 1 Type-A | 2 |
| USB 3.2 Gen 2 Type-C (20Gbps) | 1 (MSI motherboard synergy) |
| Audio Combo Jack | Yes |
| Buttons | Power, LED On/Off |
Packaging
| EAN / Barcode | 4711377231565 |
