Key Features
- 4G LTE Mobile Broadband Connectivity
- Download Speeds up to 150Mbps
- 300Mbps Wireless N Wi-Fi Performance
- Nano SIM Plug-and-Play Operation
- Supports Up to 32 Connected Devices
- Four External High-Gain Antennas
- Wi-Fi Router Mode with Ethernet WAN Support
- Fast Ethernet LAN Connectivity
Product Description
Fast and Flexible 4G Internet Access
The Mercusys MB115-4G is a reliable 4G LTE wireless router designed to provide internet access wherever fixed broadband is unavailable. Simply insert a Nano SIM card and enjoy fast mobile broadband connectivity without complex configuration or setup requirements.
Plug-and-Play Convenience
With years of compatibility testing behind it, the MB115-4G is designed for easy operation. Insert an unlocked Nano SIM card and the router is ready to share a 4G connection with multiple devices across your home, office or temporary workspace.
300Mbps Wireless N Performance
Supporting wireless speeds of up to 300Mbps on the 2.4GHz band, the router delivers reliable connectivity for web browsing, streaming, video calls, online learning and everyday networking tasks.
Strong Coverage with Four Antennas
Four external antennas enhance both LTE reception and Wi-Fi coverage, helping deliver stable connections and expanded wireless range throughout the home or office.
Flexible Router Mode
When a mobile connection is not available, the MB115-4G can operate as a traditional wireless router by connecting a broadband source to the LAN/WAN port, providing additional flexibility.
Main Benefits
-
4G LTE Connectivity: Mobile broadband speeds up to 150Mbps.
-
SIM Card Ready: Quick plug-and-play installation.
-
Wide Wi-Fi Coverage: Four external antennas improve range.
-
Supports Multiple Devices: Connect up to 32 wireless devices.
-
Flexible WAN Support: Can operate as a traditional router.
-
Compact Design: Suitable for home and office use.
-
Secure Connectivity: WPA/WPA2 wireless security.
-
Simple Management: Easy setup and operation.
General Specifications
| Specification |
Details |
| Manufacturer |
Mercusys |
| Model |
MB115-4G |
| Product Type |
4G LTE Wireless Router |
| Mobile Network Generation |
4G LTE |
| Colour |
Black |
| Installation Type |
Desktop Router |
Wireless Specifications
| Specification |
Details |
| Wi-Fi Standard |
Wi-Fi 4 (802.11n) |
| Wireless Band |
2.4GHz |
| Maximum Wireless Speed |
300Mbps |
| Supported Standards |
802.11b/g/n |
| Maximum Transmission Power |
< 20dBm |
4G Mobile Network Support
| Specification |
Details |
| Mobile Generation |
4G LTE |
| SIM Card Type |
Nano SIM |
| Supported LTE Standards |
LTE-FDD & LTE-TDD |
| Maximum Download Speed |
Up to 150Mbps |
| 3G Support |
UMTS / HSPA+ |
Supported Mobile Bands
| Band Type |
Support |
| FDD-LTE |
B1, B3, B5, B7, B8, B20, B28 |
| TDD-LTE |
B38, B40 |
| UMTS/HSPA+ |
B1, B5, B8 |
| 3G Bands |
850MHz, 900MHz, 2100MHz |
Wired Connectivity
| Port |
Quantity |
| LAN/WAN Port |
1 x 10/100Mbps |
| LAN Ports |
3 x 10/100Mbps |
| Total Ethernet Ports |
4 |
| Nano SIM Slot |
1 |
Antenna Specifications
| Specification |
Details |
| Antenna Quantity |
4 |
| Antenna Design |
External |
| Coverage Enhancement |
Yes |
| Wi-Fi Optimisation |
Enhanced Signal Stability |
Security Features
| Feature |
Support |
| WPA-PSK |
Yes |
| WPA2-PSK |
Yes |
| Wireless Encryption |
Supported |
| Protected Wireless Access |
Yes |
Network Features
| Feature |
Support |
| DHCP Server |
Yes |
| WMM Support |
Yes |
| Wireless Scheduling |
Yes |
| Wireless Statistics |
Yes |
| Wi-Fi Enable/Disable Control |
Yes |
| Router Mode |
Yes |
Physical Specifications
| Specification |
Details |
| Width |
219 mm |
| Depth |
140 mm |
| Height |
32 mm |
| Colour |
Black |
| Button Functions |
WPS / Reset |
Environmental Specifications
| Specification |
Details |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 60°C |
| Operating Humidity |
10% to 90% Non-Condensing |
| Storage Humidity |
5% to 90% Non-Condensing |
Ideal Applications
- Home Broadband Replacement
- Rural Internet Access
- Temporary Office Connectivity
- Holiday Homes & Caravans
- Remote Working
- Online Learning
- General Web Browsing
- Mobile Broadband Backup
Package Contents
- Mercusys MB115-4G Wireless N 4G LTE Router
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
Product Identifiers
| Identifier |
Value |
| Brand |
Mercusys |
| Model |
MB115-4G |
| Product Type |
4G LTE Router |
| Wi-Fi Standard |
Wi-Fi 4 (802.11n) |
| Wireless Speed |
300Mbps |
| SIM Support |
Nano SIM |
| Ethernet Ports |
1 x WAN/LAN + 3 x LAN |
| Antennas |
4 x External |
