Key Features
- 5 x Gigabit Ethernet RJ45 Ports
- 10/100/1000Mbps Auto-Negotiation on All Ports
- Auto MDI/MDIX Support
- Durable Metal Housing
- Desktop or Wall-Mount Installation
- Plug-and-Play Deployment
- Green Ethernet Power-Saving Technology
- 10Gbps Switching Capacity
Product Description
Fast and Reliable Gigabit Network Expansion
The Mercusys MS105GS is a compact 5-port Gigabit Ethernet switch designed to provide high-speed wired connectivity for homes, small offices, gaming setups and workstations. With Gigabit networking support on every port, it delivers up to ten times the speed of traditional Fast Ethernet devices while requiring no complicated configuration.
High-Speed Gigabit Performance
Equipped with five auto-negotiating Gigabit Ethernet ports, the MS105GS automatically detects and operates at the highest supported speed of connected devices. It is ideal for connecting PCs, network-attached storage, smart TVs, game consoles, printers and IP cameras.
Durable Metal Construction
The robust steel housing provides excellent durability while promoting efficient heat dissipation. Its fanless design ensures completely silent operation, making it suitable for offices, bedrooms and home entertainment environments.
Flexible Installation Options
The compact design allows the switch to be installed on a desktop or mounted on a wall, providing flexible deployment options for a wide range of networking environments.
Energy-Efficient Networking
Mercusys Green Ethernet technology automatically adjusts power consumption based on cable length and connection status, helping reduce energy usage without sacrificing network performance.
Main Benefits
-
Gigabit Speeds: Up to 1000Mbps per port.
-
Easy Expansion: Instantly adds five network connections.
-
Silent Operation: Fanless design for noise-free environments.
-
Energy Efficient: Green Ethernet technology reduces power usage.
-
Flexible Installation: Desktop or wall mounting.
-
Metal Housing: Enhanced durability and heat dissipation.
-
Plug & Play: No software or configuration required.
-
Wide Device Compatibility: Supports PCs, TVs, consoles and more.
General Specifications
| Specification |
Details |
| Manufacturer |
Mercusys |
| Model |
MS105GS |
| Product Type |
Unmanaged Gigabit Ethernet Switch |
| Switch Type |
Unmanaged |
| Installation |
Desktop / Wall Mount |
| Housing Material |
Metal |
Port Specifications
| Specification |
Details |
| Total Ports |
5 |
| Port Type |
Gigabit Ethernet RJ45 |
| Port Speed |
10/100/1000Mbps |
| Auto Negotiation |
Supported |
| Auto MDI/MDIX |
Supported |
Network Standards
| Standard |
Support |
| IEEE 802.3 |
Yes |
| IEEE 802.3u |
Yes |
| IEEE 802.3ab |
Yes |
| IEEE 802.3x |
Yes |
| IEEE 802.3p |
Yes |
Performance Specifications
| Specification |
Details |
| Switching Capacity |
10Gbps |
| MAC Address Table |
2,000 Entries |
| Packet Buffer Memory |
0.125MB (1Mbit) |
| Jumbo Frame Support |
9KB |
| Transfer Method |
Store-and-Forward |
Networking Features
| Feature |
Benefit |
| Auto MDI/MDIX |
No crossover cables required |
| Auto Negotiation |
Automatic speed detection |
| Flow Control |
Reliable data transmission |
| MAC Address Learning |
Improved traffic management |
| MAC Address Aging |
Efficient network operation |
| Half & Full Duplex |
Maximum compatibility |
Power & Efficiency
| Specification |
Details |
| Power Supply |
5V DC External Adapter |
| Input Current |
0.6A |
| Maximum Power Consumption |
3.614W |
| Green Ethernet |
Supported |
| Heat Dissipation |
12.331 BTU/h |
Design Features
| Feature |
Details |
| Housing |
Steel Metal Construction |
| Fanless Operation |
Yes |
| Wall Mountable |
Yes |
| Rack Mountable |
No |
| Stackable |
No |
| Colour |
Black |
LED Indicators
| Indicator |
Function |
| Power LED |
Power Status |
| Port LEDs |
Link / Activity Status for Ports 1-5 |
Certifications
| Certification |
Status |
| CE |
Certified |
| RoHS |
Compliant |
Environmental Specifications
| Specification |
Details |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10% to 90% |
| Storage Humidity |
5% to 95% |
Physical Specifications
| Specification |
Details |
| Width |
99.8 mm |
| Depth |
98 mm |
| Height |
25.1 mm |
| Alternative Manufacturer Dimensions |
99.6 x 98 x 25 mm |
| Installation Options |
Desktop or Wall Mounted |
Ideal Applications
- Home Network Expansion
- Small Business Networking
- Gaming Setups
- 4K Media Streaming
- IP Camera Deployments
- Network Attached Storage (NAS)
- Printer Sharing
- Remote Working Environments
Package Contents
- Mercusys MS105GS 5-Port Gigabit Desktop Switch
- Power Adapter
- Quick Installation Guide
Product Identifiers
| Identifier |
Value |
| Brand |
Mercusys |
| Model |
MS105GS |
| Product Type |
Gigabit Ethernet Switch |
| Switch Type |
Unmanaged |
| Ports |
5 x Gigabit RJ45 |
| Switching Capacity |
10Gbps |
| Jumbo Frame Support |
9KB |
| Construction |
Metal Housing |
