Description
Intel Core i3 14100F 4 Core Processor 8 Threads, 3.5GHz up to 4.7GHz Turbo, Raptor Lake Refresh Socket LGA 1700 12MB Cache, 60W, Maximum Turbo Power 110W, No Graphics,
Specs
Processor
| Processor Number: | i3-14100F |
| Total Cores: | 4 |
| # of Performance-cores: | 4 |
| # of Efficient-cores: | 0 |
| Total Threads: | 8 |
| Max Turbo Frequency: | 4.7 GHz |
| Performance-core Max Turbo Frequency: | 4.7 GHz |
| Performance-core Base Frequency: | 3.5 GHz |
| Cache: | 12 MB Intel Smart Cache |
| Total L2 Cache: | 5 MB |
| Processor Base Power: | 60 W |
| Maximum Turbo Power: | 110W |
Memory
| Max Memory Size (dependent on memory type): | 192 GB |
| Memory Types: | Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s |
| Max # of Memory Channels: | 2 |
| Max Memory Bandwidth: | 76.8 GB/s |
Expansion Slots
| PCI Express Revision: | 5.0 and 4.0 |
| PCI Express Configurations: | Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes: | 20 |
Network
| Max # of DMI Lanes: | 8 |
Physical
| Package Size: | 45.0 mm x 37.5 mm |
Other
| Essentials | Product Collection:Intel Core i3 Processors (14th gen) |
| Vertical Segment: | Desktop |
| Lithography: | Intel 7 |
| Use Conditions: | PC/Client/Tablet |
| Marketing Status: | Launched |
| Launch Date: | Q1'24 |
| Embedded Options Available: | Yes |
| Direct Media Interface (DMI) Revision: | 4.0 |
| Scalability: | 1S Only |
| Package Specifications | TJUNCTION:100°C |
| Security & Reliability | Intel Standard Manageability (ISM): Yes |
| Intel Control-Flow Enforcement Technology: | Yes |
| Intel AES New Instructions: | Yes |
| Secure Key: | Yes |
| Intel OS Guard: | Yes |
| Execute Disable Bit: | Yes |
| Intel Boot Guard: | Yes |
| Mode-based Execute Control (MBEC): | Yes |
| Intel Virtualization Technology (VT-x): | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d): | Yes |
| Intel VT-x with Extended Page Tables (EPT): | Yes |
