Description
Intel Core (BX80768265) Ultra 7 Processor 265 Processor 20 Core, 20 Threads, 2.4GHz up to 5.3GHz Turbo, LGA 1851 Socket, 66MB Cache, 65W, Maximum Turbo Power182W
Specs
Processor
| Total Cores | 20 |
| # of Performance-cores | 8 |
| # of Efficient-cores | 12 |
| # of Low Power Efficient-cores | 0 |
| Total Threads | 20 |
| Max Turbo Frequency | 5.3 GHz |
| Intel Turbo Boost Max Technology 3.0 Frequency | 5.3 GHz |
| Performance-core Max Turbo Frequency | 5.2 GHz |
| Efficient-core Max Turbo Frequency | 4.6 GHz |
| Performance-core Base Frequency | 2.4 GHz |
| Efficient-core Base Frequency | 1.8 GHz |
| Cache | 30 MB Intel Smart Cache |
| Total L2 Cache | 36 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 182 W |
| Intel Deep Learning Boost (Intel DL Boost) on CPU | Yes |
| AI Software Frameworks Supported by CPU | OpenVINO, WindowsML, DirectML, ONNX RT, WebNN |
| CPU Lithography | TSMC N3B |
| Xe-cores | 4 |
| Intel Deep Learning Boost (Intel DL Boost) on GPU | Yes |
| Sockets Supported | FCLGA1851 |
Memory
| Max Memory Size (dependent on memory type) | 256 GB |
| Memory Types | Up to DDR5 6400 MT/s |
| Max # of Memory Channels | 2 |
| ECC Memory Supported | Yes |
| AI Software Frameworks Supported by GPU | OpenVINO, WindowsML, DirectML, ONNX RT, WebGPU |
| AI Software Frameworks Supported by NPU | OpenVINO, WindowsML, DirectML, ONNX RT, WebNN |
Expansion Slots
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations ! | Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
| Max # of PCI Express Lanes | 24 |
Network
| Max # of DMI Lanes | 8 |
Rear Panel I/O Ports
| Max Resolution (HDMI)! | 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)7680 x 4320 @ 60Hz (HDMI 2.1 FRL) |
| Max Resolution (DP)! | 7680 x 4320 @ 60HzMax Resolution (eDP - Integrated Flat Panel)! 3840 x 2400 @ 120Hz |
| Intel Thunderbolt 4 | Yes |
Physical
| Package Size | 45 mm x 37.5 mm |
Other
| GPU Name | Intel Graphics |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.95 GHz |
| GPU Peak TOPS (Int8) | 8 |
| Graphics Output | eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| OpenCL* Support | 3 |
| H.264 Hardware Encode/Decode | Yes |
| H.265 (HEVC) Hardware Encode/Decode | Yes |
| AV1 Encode/Decode | Yes |
| Intel Quick Sync Video | Yes |
| # of Displays Supported ! | 4 |
| NPU Name! | Intel AI Boost |
| NPU Peak TOPS (Int8) | 13 |
| Sparsity Support | Yes |
| Windows Studio Effects Support | Yes |
| Direct Media Interface (DMI) Revision | 4 |
| Scalability | 1S Only |
| Thermal Solution Specification | PCG 2022C |
| Max Operating Temperature | 105 C |
