Description
be quiet! DARK POWER 14, 1200W, 80 PLUS certified and Cybenetics efficiency, ATX 3.1 compliant, PCIe 5.1 compatible, backed by a 10-year manufacturer's warranty.
The be quiet! Dark Power 14 1200W 80+ Titanium Power Supply is engineered for ultra-high efficiency, silent cooling, and next-generation hardware support. Designed with ATX 3.1 compliance and native PCIe 5.1 12V-2x6 connectors, it is built to power the most demanding high-end and overclocked systems. With its Titanium efficiency, advanced topology, and integrated Silent Wings cooling, it delivers exceptional performance and near-silent operation. Special Features:: Titanium efficiency, selectable cooling modes, overclocking switch, ultra-low ripple, premium capacitors, silent fan design
Specs
Chipset & Form Factor
| ATX Form Factor: | ATX 3.1 |
What's Included
| Cable Set: | Fully modular sleeved cables (up to 120cm)ATX, EPS, PCIe 5.1, PCIe 6+2, SATA, PATA |
| Dimensions without cable (L x W x H), (mm) | 175 x 150 x 86 |
Other
| Model: | Dark Power 14 | 1200W Titanium Power Supply |
| Output Power: | 1200W continuous / 1300W peak |
| Efficiency: | 80 PLUS Titanium (up to 95.4% efficiency) |
| Voltage Rails: | 4 x 12V rails (switchable to single-rail using OCK button) |
| Connectors: | 1 x ATX 20+4-pin1 x 4+4-pin CPU1 x 8-pin CPU2 x 12V-2x6 PCIe 5.14 x 6+2-pin PCIe13 x SATA2 x PATA |
| Fan: | 135mm be quiet! Silent Wings (FDB, 6-pole motor) |
| Fan Speed Control: | Active or semi-passive selectablePost-ventilation: 25 minutes cooldown |
| Fan Noise: | 8 dB(A) at 1020% load21.1 dB(A) at 100% load |
| Power Input: | 200240V AC, 50/60Hz |
| Power Output: | 12V DC (up to 1200W combined)3.3V + 5V combined: 120W |
| Protection: | OTP, OCP, OPP, OVP, UVP, SIP (no SCP listed) |
| Warranty: | 10-year manufacturers warranty |
