1 Port per unit, 100Mbps
HomePlug AV2 standard compliant, providing data transmission over electrical wires for HD video streaming
Miniature design, smaller than most powerline adapters at the market, blends discreetly in front of any power outlet
No new wires, Easy Plug and Play operation, No configuration required
Patented Power-Saving Mode automatically reduces power consumption by up to 85%
Ideal for HD Streaming
Using advanced Home Plug AV technology, TL-PA4010 KIT provides users with stable, high-speed data transfer rates over a household electric circuit for up to 300 meters. The TL-PA4010 KIT enables heavy-bandwidth applications like HD streaming, on-line gaming and large file downloading, turning your home into a robust and high-speed networking.
Miniature Design
With its new ultra-compact housing design, TL-PA4010 KIT is much smaller than TP-Link’s legacy mini powerline products. At just 28.5mm thick, it nearly blends completely in front of any power outlet.
Pair Button for Easy Network Security
Simply by pushing the Pair button on the adapters, users can set up a hassle-free Powerline network within minutes, complete with 128-bit AES encryption for network security and data protection.
It's that simple!
1. Plug the adapter into the power outlet
2. Connect the device via the network cable to the adapter
3. Press the pair buttons—and you're done!
Specifications
Standards and Protocols
HomePlug AV2, IEEE802.3, IEEE802.3u
Interface
1 x 10/100Mbps Ethernet Port
Button
Pair Button
Max. Power Consumption
Maximum: 4.60W (220V/50Hz)
Typical: 4.26W (220V/50Hz)
Standby: 0.88W (220V/50Hz)
LED
PWR, PLC, ETH
Dimensions (W x D x H)
2.6 x 2.0 x 1.1 in.(65 x 52 x 28.5mm)
Range
Up to 300 meters/1000 feet over existing electrical wiring
Modulation Technology
OFDM
Encryption
128-bit AES Encryption
Certification
CE, FCC, RoHS
System Requirements
Windows 8/7/Vista/XP/2000, Mac, Linux
Package Content
Powerline Ethernet Adapter
Ethernet cable (RJ45)
Resource CD,
Quick Installation Guide
